TOMZN ប្រភេទថ្មី Din Rail ដំណាក់កាលតែមួយ ប្តូរពេលវេលាឌីជីថលប្រចាំសប្តាហ៍ ដែលអាចកំណត់ម៉ោងបាន បញ្ជូនត គ្រប់គ្រងកម្មវិធីកំណត់ម៉ោង AC 220V 230V 12V 24V 48V 16A

TOMZN ប្រភេទថ្មី Din Rail ដំណាក់កាលតែមួយ ប្តូរពេលវេលាឌីជីថលប្រចាំសប្តាហ៍ ដែលអាចកំណត់ម៉ោងបាន បញ្ជូនត គ្រប់គ្រងកម្មវិធីកំណត់ម៉ោង AC 220V 230V 12V 24V 48V 16A

Name: TOMZN ប្រភេទថ្មី Din Rail ដំណាក់កាលតែមួយ ប្តូរពេលវេលាឌីជីថលប្រចាំសប្តាហ៍ ដែលអាចកំណត់ម៉ោងបាន បញ្ជូនត គ្រប់គ្រងកម្មវិធីកំណត់ម៉ោង AC 220V 230V 12V 24V 48V 16A
Brand: TOMZN
SKU: 1005005630151687-12V AC DC-30A
Price: 10.55 USD
Availability: InStock

by ដោយ TOMZN

$0.00 - $0.00

$0.00

$10.55

$10.55 - $10.55

$10.55

Availability:

1931 in stock, ready to be shipped

Availability:

1966 in stock, ready to be shipped

Availability:

1140 in stock, ready to be shipped

Availability:

1797 in stock, ready to be shipped

Availability:

1949 in stock, ready to be shipped

Availability:

1991 in stock, ready to be shipped

Availability:

1993 in stock, ready to be shipped

Availability:

1998 in stock, ready to be shipped

Availability:

1978 in stock, ready to be shipped

Availability:

1989 in stock, ready to be shipped

Quantity

TOMZN ប្រភេទថ្មី Din Rail ដំណាក់កាលតែមួយ ប្តូរពេលវេលាឌីជីថលប្រចាំសប្តាហ៍ ដែលអាចកំណត់ម៉ោងបាន បញ្ជូនត គ្រប់គ្រងកម្មវិធីកំណត់ម៉ោង AC 220V 230V 12V 24V 48V 16A

All prices exclude shipping Customs and taxes. តម្លៃទាំងអស់មិនរួមបញ្ចូលថ្លៃដឹកជញ្ជូន គយ និងពន្ធទេ។

SPECIFICATIONS

Brand Name: TOMZN

Certification: CE,RoHS

Contact Load: High Power

EU LVD Voltage: High voltage: Above 50Vac or 75Vdc

High-concerned chemical: none

Model Number: AHC15A, AHC30A

Origin: Mainland China

Protect Feature: Sealed

Theory: Time Relay

Use: General Purpose

Voltage: 12V,24V,48V,110V,220V

is_customized: Yes

Product attributes

AC DC means the products can work with AC and DC current

AC means the products only work with AC current.

Panel mounted

Advanced pre-setting one week before

Digital electronic timer switch with daily and weekly programs

Repeat programs with 16 on/off setting and manual override

NiH battery power reserve when electric supply cut off

Technical Data:

Model	AHC15A, AHC30A
Temp.range: -20°C+50°C	Power Supply: accorind your order
Power consumption 4.5 VA (MAX)	Display: LCD
Switching contact: 1 changeover switch	Programs:16 on/off each day or week
Hysteresis 2 sec/day (25°C)	Mini interval: 1min
Capacity: 16(8) 250V AC	Black-out: 60 days
Timer range: 1min~168hr	Recharge battery: 1.2V 40Ma
Average error: 1s/24h, 25°C	Weight: 0.15kg
