New Type Din Rail 2 Wire Weekly 7 Days Programmable Digital TIME SWITCH Relay Timer Control AC 220V 230V 12V 24V 48V 16A

Name: New Type Din Rail 2 Wire Weekly 7 Days Programmable Digital TIME SWITCH Relay Timer Control AC 220V 230V 12V 24V 48V 16A
Brand: TOMZN
SKU: 1005002492499686-12V AC DC-30A
Price: 8.95 USD
Availability: InStock

by ដោយ TOMZN

All prices exclude shipping and taxes. តម្លៃទាំងអស់មិនរួមបញ្ចូលថ្លៃដឹកជញ្ជូន និងពន្ធទេ។

Choose language

New Type Din Rail 2 Wire Weekly 7 Days Programmable Digital TIME SWITCH Relay Timer Control AC 220V 230V 12V 24V 48V 16A

SPECIFICATIONS

Brand Name: TOMZN

Certification: NONE

Contact Load: High Power

EU LVD Voltage: High voltage: Above 50Vac or 75Vdc

High-concerned chemical: none

Model Number: AHC15A, AHC30A

Origin: Mainland China

Protect Feature: Sealed

Theory: Time Relay

Use: General Purpose

Voltage: 12V,24V,48V,110V,220V

is_customized: Yes

Product attributes

AC DC means the products can work with AC and DC current

AC means the products only work with AC current.

Panel mounted

Advanced pre-setting one week before

Digital electronic timer switch with daily and weekly programs

Repeat programs with 16 on/off setting and manual override

NiH battery power reserve when electric supply cut off

Technical Data:

Model	AHC15A, AHC30A
Temp.range: -20°C+50°C	Power Supply: accorind your order
Power consumption 4.5 VA (MAX)	Display: LCD
Switching contact: 1 changeover switch	Programs:16 on/off each day or week
Hysteresis 2 sec/day (25°C)	Mini interval: 1min
Capacity: 16(8) 250V AC	Black-out: 60 days
Timer range: 1min~168hr	Recharge battery: 1.2V 40Ma
Average error: 1s/24h, 25°C	Weight: 0.15kg
